Magnesium Oxide Boards
Intertek rated for ASTM E119-20 and exceeds CAN/ULC S101-14 testing.
-
ArkiShield Magnesium Oxide Panel
Vendor:ArkitorRegular price From $39.17 CADRegular priceUnit price / per -
ArkiCore Magnesium Oxide Panel
Vendor:ArkitorRegular price From $37.79 CADRegular priceUnit price / per -
ArkiFloor Magnesium Oxide Panel
Vendor:ArkitorRegular price $151.66 CADRegular priceUnit price / per
ArkiBoard Applications
-
Exterior Wall
ArkiShield magnesium cement boards are a fireproof sheathing design for exterior walls. It is made from reinforced Magnesium Oxysulfate cement, grade E mesh fibre, and waterproof polymers. ArkiShield is the leading chloride-free MgO board and has passed all the durability tests of EN 12467(fibre-cement sheathing standard). It is a fireproof and cost-effective sheathing, highly recommend for tile, brick, stone veneer substrate, ETICS underlay, aluminum curtain wall substrate and stucco substrate etc.
-
Interior Wall
ArkiCore magnesium cement board is an ideal interior wall application in high moisture and wet areas like the kitchen and bathroom. ArkiCore is a fire-resistant wallboard that has passed the ASTM E119 and has proven to be a 1-hour fire-rated building material. ArkiCore is also water-resistant and mold-resistant, which is a much better building material than OSB or Gypsum board in wet and high moisture areas. We provide tapered edge and square edge boards for easy installation.
-
Ceiling & Floor Board
ArkiFloor is ideal for use in interior ceilings and sub-floor board applications. Using a 10mm thickness board for the ceiling and a 19mm thickness board for the sub-floor board can give you a 2-hour fire separation. ArkiFloor is good for fire-resistance, water-resistance and sound insulation. We offer tapered edge, square edge, and tongue & groove edge boards for easy installation.
ArkiBoard Properties
-
Fire Resistance
- Incombustible Class A1
- Flame spread None Class A
- Smoke emission None Class A
-
Moisture Resistance
- Waterproof coating surface
- Maintains high strength in wet condition
-
Mold Resistance
- Resistant to mold
- Resistant to fungus
-
Pest Resistance
- MGBoard with a steel frame structure provides 100% termite and pest resistance
-
Impact Resistance
Reinforced with mesh glass fibers provides structural resistance
- Hammer Pounding
- Panel Drops
- Edge Impact
-
Thermal Resistance
Low heat transfer rate which is much lower than most inorganic building materials, 0.218(M2.K)/W
-
Flexible
12mm thickness MGBoard has a bending strength of over 1350 Newtons or 303.4 lbf.
-
Durable
- Passed 50 times soak & dry cycles
- Passed 50 times heat rain cycles
- Passed 100 times freeze-thaw cycles
-
SIP Sheathing
- 40-60 minutes fire protection
- Screw holding > 700-900N
- High bending & impact strength
-
Easy Installation
- Utility knife cutting, sawing, nailing, drilling
- Plastering & painting same as gypsum board and fiber cement board.
-
Building Safe
- Resistant to fire, water, mould, and termites
- 20 years factory warranty with "No Metal Corrosion"
-
ECO & Safe
- Abestos and formaldehyde free
- Materials Safety meets European REACH regulation.
Wholesale Inquiries
Collection: Magnesium Oxide Board
Upgrade your construction projects with Arkitor MGShield Boards, the ultimate magnesium oxide (MgO) panels for exterior sheathing, siding, and sub-flooring. Engineered for fire resistance, weatherproofing, and sustainability, MGShield is the ideal choice for residential, commercial, and industrial applications.
Why MGShield?
- Fire-Resistant: Class A1 incombustible rating with no flame spread, certified under ASTM E119 and CAN/ULC S101.
- Weatherproof: Reinforced with chloride-free magnesium cement, passing EN 12467 durability tests.
- Eco-Friendly: Free from asbestos, formaldehyde, and harmful chemicals, meeting European REACH standards.
Key Applications
- Exterior Walls: Perfect for tile, stone veneer, ETICS underlay, aluminum curtain walls, and stucco.
- Interior Walls: Mold- and moisture-resistant for kitchens, bathrooms, and high-humidity spaces.
- Ceilings & Floors: Fire-rated and sound-insulated boards in thicknesses from 6mm to 19mm.
Built to Last
- Impact Resistant: Reinforced with mesh glass fiber for superior strength.
- Customizable Sizes: Available in multiple thicknesses and lengths up to 10 feet.
- 20-Year Warranty: Backed by proven durability and performance.
Discover the Difference with Arkitor MGShield.
Contact us today to request a quote or learn more about our product line.
